IPhone7 battery replacement_mobile phone repair installation graphic tutorial

by:YoukingTech     2021-08-23
Posted on 04.28, a brief overview of the iPhone7 battery replacement graphic tutorial, please watch the tutorial video of for details. Method/Step Take out a battery tape and tear off the protective film on one side, usually the blue one. 1 Then stick the battery tape to the battery. PS: Pay attention to the side of the battery ground, and the big end of the battery tape is near the side of the cable. It happens that the edge of the tape is close to the edge of the battery (the section where the battery tape is exposed is not counted). 2 Then you can install the battery. When installing, buckle the battery cable buckle first, and then correctly align the battery position. PS: Because once the battery is pasted, the position cannot be corrected. Fasten the cable buckle first, and there will be basically no problem with the position of the battery, so that the battery cable buckle cannot be buckled after installing the battery. 3 After pasting, paste the exposed tape on the top of the battery. PS: It is convenient to remove the battery next time. 4 Install the vibrator. PS: The direction is right. 5 Fasten the vibrator cable buckle. 6 Install the cable holder and install the fixing screws on it. 7 Install the vibrator fixing screws. 8 Use a spudger to clean the sealing tape remaining around the lower frame. 9 Then paste the waterproof sealer glue. PS: The waterproof effect of the waterproof glue pasted after disassembling the machine is very unsatisfactory, and after sticking the tape, it is not convenient to merge the screen. You can consider not sticking waterproof glue. 10 Fasten the front camera cable buckle, then install the fixing iron plate on it, and use a Phillips screwdriver to install the fixing screw on it. 11 Then turn the screen over, buckle the LCD cable buckle, and install the upper shielding cover. And use a Y-shaped Samsung screwdriver to install the fixing screws above. 12 Power on and check the function of the mobile phone to see if some functions are lost due to the loss caused by disassembling the phone. 13 After checking that the phone is functioning normally, merge the screens. If it does not close, please check if the lower accessories are installed correctly or if there is something stuck. 14 Using a pentagonal screwdriver, install the two pentagonal screws under the phone. 15 Video viewing address→!10~1!2~3~A 16
